| Place of Origin: | Hebei , China |
| Brand Name: | ZH |
| Certification: | CE |
| Model Number: | ZH-1000 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD8000-15000 per set |
| Packaging Details: | One set machine needs one 40GP for shipment , PLC system packed with Carton box . |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
| Type: | Roofing Corrugated Sheet Roll Forming Machine | Feature: | Advanced Design |
|---|---|---|---|
| Special: | Hydraulic Cutting | Power: | 4+4KW |
| Volgate: | 380V Or Custom | Roller: | No.45 Steel With Heat Treatment |
| Warranty: | 1 Year Free | Service: | Whole Life |
| High Light: | corrugated sheet roll forming machine,roll former machine |
||
High Speed Roofing Corrugated Sheet Roll Forming Machine with Track cutting 35m/min
WhatsApp/Wechat : +8615720370230
High Speed Roofing Corrugated Sheet Roll Forming Machine with Track cutting 35m/min
| Description | Specification | |
| Main moter power | 5.5KW | |
| Hydraulic station power | 4KW | |
| Hydraulic oil pump | CB-E310 | |
| Sprocket | P-25.4 | |
| Roller station | 14 | |
| Yield strength | 32MPa | |
| Diameter of principal axis | 75MM | |
| Material of roller | 45#steel hard chrome plating | |
| Processing speed | 8m/min | |
| Thickness | 0.3-1mm | |
| Installation dimension about(L*W*H) | 7.5*1.5*1.2M | |
| Total weight | 3.8T | |
| Equipment parts includes:forming machine,hydraulic cutter,hydraulic station,electric controlling system,counter,product supporter | ||
Corrugated Sheet Roll Forming Machine is a special machine, can produce various width of sheets without any mould change, only adjusting the feeding guiding.
Corrugated sheet is a very important cladding element for commercial, residential and industrial roofing and walling. The traditional shape of corrugated material is the round wavy style derived from sinus curve. And today a lot of corrugated profiles come out to meet the needs of different applications. If you have your conjugation profile, let’s customize the corrugated sheet roll forming machine for you. Furthermore , ZHONGHENG have several design of metal sheet roll forming machines for corrugated sheets. And we are the manufacturer of China Roll Forming Machine
Traditional corrugated profile is 914mm as the feeding width, 762mm as the covering width, 76.2mm as the pitch(distance between two consecutive curves), and 18mm as the depth(wave height). Also, there are mini corrugated profile, deep corrugated profile, etc. In South African, customer always buy a double layer roll forming machine for IBR sheets and corrugated sheets instead of IBR sheet roll forming machine and corrugated sheets roll forming machine. Finally to save money and factory space.
What’s Corrugated Sheet Roll Forming Machine?
Corrugated sheets roll forming machine is very special, Because the machine accept different input width coil to get different out width product. ZHONGHENG have 18-76.2-1000 type machine, it’s obvious that 1000mm output width is the standard width or design width. While you use 1250mm width coil, you will get 1000mm corrugated sheet. While 1000mm width coil, 838mm output. And while 914mm width coil, 762mm output product, only adjust the feeding guide.
ZHONGHENG also have Mini Orb Corrugated Sheets Roll Forming Machine, the product is famous in South African
