Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine

Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine

    • Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine
    • Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine
    • Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine
    • Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine
  • Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine

    Product Details:

    Place of Origin: China
    Brand Name: ZHONGHENG
    Certification: CE/SGS/ISO9001
    Model Number: ZH24-200-1000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD10000-15000/set
    Packaging Details: Waterproof plastic film cover
    Delivery Time: 25working days
    Payment Terms: Western Union, T/T, L/C
    Supply Ability: 300 sets/months
    Contact Now
    Detailed Product Description
    Suitable Material: PPGI,PPGL,GL Thickness Of Material: 0.3mm-0.8mm
    Type: Roll Forming Machine Use: Roof
    Production Capacity: 15 M/min(Adjustable) Power: 5.5kw+4kw
    Weight: 4 Ton Warranty: 24 Months



    Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine



    Specification



    NO.

    ITEM

    PARAMETER

    NOTE

    1.







    Suitable

    material



    Type

    Pre-painted sheet,

    Galvanized sheet



    Width(mm)

    1200mm



    Thickness(mm)

    0.3-0.8mm



    Yield stress(mm)

    G220-G300



    2.

    Product

    specifications

    Detail as the attached file

    Length

    Any length



    3.

    Power

    requirement



    Type

    380v/3ph/50hz

    Motor brand shanghai Lichao

    Main Motor power

    5.5kw

    Cutter power

    4kw

    4.

    Forming speed(m/min)

    10-15m/min

    Not include the time of cutting

    5.

    Manual Decoiler



    (Optional)

    Type

    Manual



    Max capacity

    5t



    Suitable coil OD(MM)

    1000



    Suitable coil

    ID(MM)

    508



    6.

    Forming stand

    16

    Depend on actual design

    7.

    Thickness of structure

    16mm



    8.

    Forming shaft diameter(mm)

    70 solid



    9.

    Type of cutting

    Roll formed and

    length-set cutting



    10.

    Control system

    Panasonic PLC and inverter



    11.

    Install dimension(depend on the final design)

    8.2m×1.5m×1m

    Without panel length

    12.

    Total weight (Approx)

    5.5T

    Depend on final design



    Description

    1) we have about 12 years experience in the steel roll forming machines area.so for the design and produce there are much experience and professional people.



    2) quality control,we have CNC process to produce the rollers,grinder machine to smooth the frame.make more precise.and less tollerance.and after assebling,inspect the whole machine and result before delivery.



    3) we have professional engineer in charge of installation abroad.after services are easy way solution.



    4) on time delivery.



    5) quality garantee,one year time garantee,and service all the life.

    Flow chart

    Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Auto cutting

    Products receiving

    Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine



    Applications:



    Roof panel are widely used in building: the steel-structured large-scale warehouses, plants, supermarkets,

    shopping malls, trade markets, stadiums, holiday villages, sanatoriums, hotels, villas, residences, and

    different kinds of greenhouses. What's more, equipment can be designed and manufactured as customers'

    requests.This model is hot in Middle east.



    Competitive Advantage:

    1. save space

    2. easy installation

    3. perfect service

    4. excellent quality

    5. Operate easily



    Corrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making MachineCorrugated Color Steel Frame Roll Forming Machine 0.8mm Tile Making Machine
